Onyx ACCEL-VM200 Medical PC
$2,799.99 AUD
Approx $1,917.99 USD
Description:
Onyx ACCEL-VM200 Medical PC
AV over IP Master Controller.13W EU MedicalPower adapter
Specifications
| Outport Port | 1x HDMI |
| Control I/O | 1x IR Extender (3.5mm) 1x RS-232 (3-pin Terminal Block) 8x Trigger (10-pin Terminal Block) 1x USB (Type-A) 2x LAN (RJ-45) |
| Reserved Port | 1x RS-232 (5-pin Terminal Block) |
| Maximum Output | HDMI |
| Maximum Resolution | 1920 x 1080 @ 60fps |
| Power Supply | 5V/2.6A DC (Locking) |
| Power Consumption | 2.99W |
| Chassis Material | Metal (Steel) |
| Chassis Colour | White |
| Dimensions (W x H x D) | 231.5 × 25 ×108 mm (Case Only) 231.5 x 25 x 117 mm (All-Inclusive) |
| Weight | 250g |
| Certification | CE: EN 60601-1-2:2015(V4.0), EN 60601-1:2006/A1:2013/A12:2014 (V3.1) FCC: Part 18 Class A |
Onyx ACCEL-VM200 Medical PC: Advanced AV Control for Digital Operating Rooms
Description
The Onyx ACCEL-VM200 is a compact, fanless medical-grade PC designed to serve as an AV over IP master controller for digital operating rooms (ORs). This device enables seamless management and configuration of multiple compatible video over IP (VoIP) extenders through a single WebGUI, facilitating efficient control of video signals in high-acuity environments. With its robust build and compliance with medical standards, the ACCEL-VM200 is tailored for integration into modern surgical settings.
Key Features
- AV over IP Master Controller: Manages and configures multiple VoIP extenders via a centralized WebGUI.
- Dual LAN Ports: Allows control over VoIP installations on separate networks, enhancing flexibility.
- Trigger Control Keypad Support: Enables easy, single-button preset activation for streamlined operations.
-
Compact and Fanless Design: Dimensions of 231.5 × 25 × 108 mm and weight of 250g make it suitable for space-constrained
environments.
-
Medical-Grade Certification: Complies with CE: EN 60601-1-2:2015(V4.0) and EN 60601-1:2006/A1:2013/A12:2014 (V3.1)
standards, ensuring safety and reliability in medical settings.
- Low Power Consumption: Operates at 2.99W, contributing to energy efficiency in the OR.
-
Multiple Control Interfaces: Includes HDMI output, RS-232, USB Type-A, and trigger ports for versatile connectivity.
Benefits
-
Enhanced Workflow Efficiency: Centralized control of video signals reduces the complexity of managing multiple devices,
streamlining OR operations.
-
Improved Video Signal Management: Dual LAN ports enable segregation of video traffic, optimizing network performance and
reliability.
-
User-Friendly Operation: Support for trigger control keypads allows for quick and easy activation of preset configurations,
minimizing the need for manual adjustments.
-
Space-Saving Design: The compact, fanless chassis is ideal for integration into space-constrained environments without
compromising on performance.
-
Compliance with Medical Standards: Adherence to international medical certifications ensures the device meets stringent
safety and performance requirements.
Why Choose the Onyx ACCEL-VM200?
The ACCEL-VM200 is specifically designed to meet the demands of modern digital operating rooms. Its compact size, low power consumption, and compliance with medical standards make it an ideal choice for healthcare facilities seeking to enhance their AV control capabilities. By centralizing video signal management and offering flexible control options, the ACCEL-VM200 contributes to more efficient and streamlined OR operations.
Conclusion
The Onyx ACCEL-VM200 Medical PC is a robust and efficient solution for managing video signals in digital operating rooms. Its advanced features, compact design, and compliance with medical standards make it a valuable asset for healthcare facilities aiming to optimize their surgical environments.
