Shuttle SH610R4 LGA1200 Dual Ethernet Barebones Workstation
$1,189.99 AUD
Approx $832.99 USD
Description:
Shuttle SH610R4 LGA1200 Dual Ethernet Barebones Workstation
Intel ® 14th/13th/12th Gen LGA1700 socket , H610 chipset, 300W, 1x LAN, PCIEx 16, PCIEx 1, R4 chassis, 2x 3.5" HDD, 1x 5.25" ODD, Triple displays
Specifications
| Form Factor | Shuttle Form factor |
| Processor | Support Intel® 12th/13th/14th generation Core™ i3/i5/i7/i9, Pentium®, Celeron®125W LGA1700 CPU |
| Chipset | Intel H610 express chipset |
| Memory | (2) DDR4 3200 MHz support, dual channel up to 64GB (32GB*2) |
| Video Output | (1) HDMI + (2) DisplayPort +(1) VGA , support triple independent display 4K/60Hz playback (With Integrated Graphic in CPU) |
| Audio | Realtek ALC888S 5.1 Channel high definition audio |
| Ethernet | Intel i219 10Mb/s,100Mb/s,1Gb/s operation Support Wake-On-LAN function |
| Storage Interface | SATA 6.0Gb/s interface |
| Onboard Graphics | (2) 4 Pin fan connector (3) SATA gen3.0 connector (1) ATX main power (2*10) (1) ATX 12V power (2*2) (1) 1X5 USB 2.0 header (1) RS232 header (1) Front AUDIO header (2) Front USB FFC header |
| Front Panel | (2) USB 3.2 Gen 1 port (1) Microphone-In (1) SPK-Out (1) Power button (1) Power LED (1) HDD LED |
| Back Panel | (4) USB 2.0 Port (2) USB 3.2 Gen 1 Port (1) LAN (1) HDMI port (2) Display port (1) VGA port (1) Audio Mic in (1) Audio Line in (1) Audio SPK out (1) External 4pin header (3) Antenna Hole |
| Drive Bay | (1) 5.25" ODD bay (2) 3.5" HDD bay |
| Dimensions | 329(L) x 216(W) x 198(H) mm |
| Expansion Slot | (1) PCI-E X16 Gen5.0 slot (1) PCI-E X1 Gen3 slot (1) M.2 2280 type M key socket (1) M.2 2230 type E key socket |
| OS Support | Windows 11 Linux |
| Weight | 3.7kg |
Shuttle SH610R4 LGA1200 Dual Ethernet Barebones Workstation
The Shuttle SH610R4 LGA1200 Dual Ethernet Barebones Workstation is a compact and versatile computing solution designed for professionals seeking high performance in a small form factor. Powered by the Intel® H610 chipset, this mini PC supports 12th, 13th, and 14th generation Intel® Core™ processors with a maximum TDP of 125W, offering robust performance for demanding applications.
Key Features
-
Processor Support: Compatible with Intel® 12th, 13th, and 14th generation Core™ processors (i9, i7, i5, i3), Pentium®, and
Celeron® with a maximum TDP of 125W. Note: For 14th generation processors, a BIOS update is required.
-
Memory: Supports up to 64GB of DDR4-3200MHz memory across two DIMM slots, providing ample capacity for multitasking and
memory-intensive applications.
-
Graphics: Integrated Intel® UHD Graphics, capable of supporting triple independent 4K displays via HDMI 2.0b and
DisplayPort 1.4 outputs. Note: Processors with an "F" suffix do not include integrated graphics.
-
Expansion Slots: Features a PCIe x16 v5.0 slot for dual-slot graphics cards (up to 273mm in length) and a PCIe x1 v3.0 slot
for additional expansion cards.
-
Storage: Offers multiple storage options, including one 5.25" optical drive bay, two 3.5" SATA bays, and two M.2 slots
(M.2-2280 for SSDs and M.2-2230 for optional WLAN modules).
-
Connectivity: Equipped with dual Gigabit Ethernet ports (Intel i219), four USB 3.2 Gen 1 ports, four USB 2.0 ports, one
HDMI port, two DisplayPort 1.4 ports, one VGA port, and audio in/out jacks, providing versatile connectivity options for various peripherals
and networks.
-
Cooling: Utilizes Shuttle's exclusive I.C.E. 2 heat pipe technology for efficient cooling, ensuring stable long-term
operation.
-
Power Supply: Includes a 300W 80 PLUS Bronze certified internal power supply, providing reliable power for the system.
-
Operating System Support: Compatible with Windows 10/11 (64-bit) and Linux (64-bit), offering flexibility in operating
system choice.
Benefits
-
Compact Design: With a volume of just 13.4 liters, the SH610R4 offers a small footprint without compromising on
performance.
-
High Performance: The combination of a powerful processor, ample memory, and integrated graphics ensures smooth operation
for demanding applications.
-
Versatile Connectivity: Multiple USB ports, dual Gigabit Ethernet, and support for triple 4K displays provide extensive
connectivity options for various peripherals and networks.
-
Flexible Storage Options: Multiple storage bays and M.2 slots allow for customization based on storage needs.
-
Efficient Cooling: The I.C.E. 2 heat pipe technology ensures efficient cooling, maintaining optimal performance even under
load.
Why Choose the Shuttle SH610R4?
The Shuttle SH610R4 LGA1200 Dual Ethernet Barebones Workstation is an excellent choice for professionals seeking a compact, high-performance computing solution. Its powerful processor support, ample memory capacity, and versatile connectivity options make it ideal for applications such as digital signage, video conferencing, and office environments where space is limited but performance is essential.
Conclusion
In conclusion, the Shuttle SH610R4 LGA1200 Dual Ethernet Barebones Workstation offers a compelling combination of performance, compact design, and versatility. Whether you're looking to enhance your digital signage setup, deploy a silent office workstation, or create a powerful home theater PC, the SH610R4 provides the performance and flexibility needed to meet your requirements.
